Metal Pipe Fiber Optical Laser Tube Cutting Machine Suppliers

Model: PE-F3015B


Introduction

Perfect Laser is a world leading enterprises specializing in the laser cutting field.

This PE-F3015B fiber-optic tube and pipe laser cutting machine is a high-tech cutting product developed by Perfect Laser.

The pipe laser cutting machine adopts Japanese import Panasonic servo motor and driving system, Taiwan famous HIWIN linear guide rail, and can cut metal sheet, metal round pipe and tube at the same time.

The pipe cutting diameter can reach 200mm.

(It can also be customized according to customer’s needs).

The production efficiency of the pipe laser cutting machine is greatly improved.

Product Features

1. With High precision, the laser tube cutting machine is most suitable for precision parts processing and various fine metal cutting.

2. The numerical control system is simple and easy to learn, and the operation of the laser tube cutting machine is also very simple.

3. This laser tube cutting machine adopts the integrated design of pipe and tube, which saves space, leads to higher production efficiency and creates higher profit.

4. One machine can be used to cut both pipe and sheet plate to solve the problem of cutting specially-shaped parts.

5. The tube laser cutting machine can quickly cut work-pieces of different shapes and sizes with fast speed and high precision, saving processing cost and reducing production cost.

Tag:laser tube cutting machine, pipe laser cutting machine, tube laser cutting machine

Application


The tube laser cutting machine is widely used in sheet metal cutting, including: hardware products, kitchen appliances, precision machinery equipment, lighting hardware, precision parts and other metal cutting industries, for cutting stainless steel, carbon steel, mild steel, alloy steel, aluminum alloy, titanium and many pipe and tubes.


Technical Data

Product Name

Tube Laser Cutting Machine

Model

PE-F3015B

Laser Power

500W / 1000W / 1500W / 2000W / 2500W / 3000W

Transmission Method

High Precision Gear Transmission

Table-driven system

Japanese Import Panasonic Servo Motor & Driving System

Focus Method

Dynamic Auto-Focusing System

Control Method

DSP Handle Offline Movement Control

Metal Sheet Processing Working Area

1500×3000x150mm

Pipe Type

Round, Oval, Some Special-Shaped Metal Pipe

Pipe Length

<12 Meters

Cutable Pipe Length

< 6 Meters

Pipe Diameter

20-300mm

(Also can be customized according to user’s requirement)

Maximum Idling Speed

90m/min

Laser Wavelength

1080 nm

Minimum Cutting Line Width

0.1mm

Rated Output Power

50-2000W

X, Y-axis Positioning Accuracy

≤±0.01mm

Repeated Positioning Accuracy of Table

≤±0.01mm

The Maximum Load of the Workbench

800 Kgs

Z-axis Travel

120mm

Volume

4.6×2.3×1.8m

Power

12KW

Water Chiller

2kw

Electricity Power

380v 50Hz (±10%)

Red Light Spot Position

Yes

Auxiliary Gas

Oxygen, Nitrogen Gas

Control software

Perfect Laser Professional Metal Sheet and Metal Pipe Laser Cutting Software

Guarantee

2 Years Guarantee for Fiber Laser Source

12 Month Guarantee for Fiber Laser Cutting Machine

Training

Perfect Laser Will Offer VCD Training Video for Easy Learning Engineer Overseas Installation & Training is also Available
