Aluminum


Laser Cut Aluminum


Aluminum is a highly reflective material that does not absorb laser light, so neither a fiber laser cutting machine nor a YAG laser cutting machine can cut thick aluminum.

Generally, 6000W fiber laser cutting machine can cut 14mm aluminum and aluminum alloy which is the thickest.




Fiber lasers are widely used to cut aluminum and its alloys. Fiber laser cutting machines have a good performance rating when used in cutting aluminum or other materials, such as stainless steel, carbon steel, etc.




Since aluminum is not resistant to high temperatures, burns are prone to occur during the cutting process. Thus, it is necessary to focus on controlling the process.

To achieve the desired cut quality, the cutting speed also needs to be controlled. If it is too fast, it is prone to burns, If it is too slow, It will cause cracks on the material, thereby affecting the quality of the cut.




Generally, for laser cutting equipment of the same voltage, the cutting speed of the fiber laser cutting machine is higher than that of the YAG cutting machine.




The fiber laser cutting machine of Perfect Laser can meet the cutting of aluminum and its alloys. Please choose the most suitable model according to your needs.




(Below is the theoretical data, the actual cutting thickness may vary slightly depending on the type and purity of the material)


Material

Thickness

(mm)

Maximum cutting speed (m/min)

500W

700W

1000W

1500W

2000W

2500W

3000W

4000W

6000W

aluminum

1mm

2

7

12

16

24

25

26

40

50

2mm

0.9

3

6

6

10

11

12

18

30

3mm

/

1

2

2.5

4.5

5.8

7.2

10

16

4mm

/

0.6

1

1.3

2.5

3

3.6

5.5

12

5mm

/

/

0.6

1.2

1.8

2.3

2.7

3.7

10

6mm

/

/

/

0.6

1.2

1.5

1.8

2

5.5

8mm

/

/

/

/

0.6

0.7

0.9

1

2

10mm

/

/

/

/

/

0.6

0.7

0.8

1

12mm

/

/

/

/

/

/

/

0.6

0.7

14mm

/

/

/

/

/

/

/

/

0.6



For more details for the product, please click:

For 1-2mm Aluminum Cutting: 500W Fiber Laser Cutting Machine

For 1-5mm Aluminum Cutting: 1000W Fiber Laser Cutting Machine

For 1-6mm Aluminum Cutting: 1500W Fiber Laser Cutting Machine

For 1-8mm Aluminum Cutting: 2000W Fiber Laser Cutting Machine

For 1-10mm Aluminum Cutting: 3000W Fiber Laser Cutting Machine

For 1-12mm Aluminum Cutting: 4000W Fiber Laser Cutting Machine

For 1-14mm Aluminum Cutting: 6000W Fiber Laser Cutting Machine


Fiber laser cutting machine not only meets the cutting requirements of aluminum alloy but also meets the cutting requirements of many other metal materials,such as iron, zinc, gold, silver, copper, brass, stainless steel, titanium, carbon steel and other metal sheet and pipe cutting.
